(Hamlib works too but I am not going to cover that.)Ĭlick on the "RigCAT" subtab to bring up the RigCAT configuration window.Ĭlick the "Open" button next to the "Rig description file:" box. Fldigi supports several ways to communicate with your rig. Set up RigCAT to control HDSDR and vice-versa.Ĭlick the "Rig" tab at the top of the configuration window. Ifyou see the following error message, "PortAudio error: Invalid sample rate," click on the "Settings" sub-tab and set both the Capture and Playback sample rates to 48000 to match the setting for VAC in HDSDR.Īs long as you are at the "Settings" window for "Audio" you can check the following:įor the sample rate converter ("Converter") set "Medium Sinc Interpolator" if it isn't already set. I found that I have had trouble with fldigi getting the sample rate correct when in "Auto" or "Native" mode. The waterfall should come alive just as soon as you set the proper virtual cables for input and output.
If the "Devices" sub-tab is not selected, select it.Ĭlick the "PortAudio" selection button if it is not already selected. The "Fldigi configuration" window will pop up with the "Audio" tab selected. It doesn't matter where you start but you need only configure "Sound Card" and "Rig Control" to get fldigi working with HDSDR.Ĭlick "Sound Card" to start the configuration of fldigi to use VAC to communicate with HDSDR. Click on the "Configure" menu item to perform the configuration process for fldigi. You may get an error message because the audio input has not been selected.
Fldigi interface windows#
Note: in Windows 7, you must run FLDIGI first to see the Rigs folder.
Place the RigCAT description file for TS-50, i.e.
C:\Users\\fldigi.files\rigs (assuming Win 7). On Windows, fldigi keeps its configuration files in the fldigi.files directory (folder) in the user's home directory, i.e.
Fldigi interface install#
HDSDR so that means you have installed the Windows version of fldigi.) Install the RigCAT XML description file for Kenwood TS-50 transceiver. (This document assumes that you are running fldigi on the same computer that is running Setting up the port-pair is nothing more than selecting the desired values for End 1 and EndĢ, COM7 and COM8 in this case, and clicking the "Create Pair" button. Therefore, creating a port-pair where both COM numbers are below 9 means that the configuration may be used later on to communicate with these other programs. WSJT and WSPR, have problems with port numbers above 8. Most of the examples use COM6/COM16 or COM7/COM17 but Iĭiscovered that some programs, e.g. In my case I created port pair COM7/COM8 for communications between It is possible for virtual ports to conflict with physical ports if the physical ports are added later.
Fldigi interface serial#
Make sure that your virtual port pair starts above any possible physical serial port numbers. It will show you your physical serial ports and offer to create a virtual port pair. Both rig control and PTT will be handled by this single port-pair. dl-fldigi will run just fine without make installing, if you prefer.For now you will create a single port-pair that will be used for CAT control of fldigi by You will now have a copy of dl-fldigi at src/fldigi. You can now continue with the build process as before. You now need to edit the file src/Makefile.am and comment out the line that starts “TESTS =” (line 229) by adding a # to the start of the line. $ sudo apt-get install libxmlrpc-c++8-dev $ git clone git:///ukhas/dl-fldigi.git $ sudo apt-get install git-core libcurl4-openssl-dev libjpeg62-dev autoconf Install main dependencies (Same as listed above) (Similar fixes to src/Makefile.am are needed for later versions of Fedora as well) To install the released version on ubuntu 14.04 as opposed to the bleeding edge version some additional steps are required.
